WATTMASTER AC DC Digital Clamp Meter WATEL-9015

Features

• Professional grade clamp meter for troubleshooting and preventive measurements
• True RMS technology
• Large backlight display with flexible, robust design
• Auto-ranging feature and automatic power off
• Data hold function and overload protection
• Single rotary switch for easy function selection
• Maximum jaw opening size: 30mm
• Meets IEC 61010-1 standards
• Includes test leads, temperature probe, batteries, carrying case, and operating instructions

Specifications

• Measuring circuit category: CAT IV 600V, CAT III 1000V
• Display count: 3 5/6 digit, 6000
• AC voltage range: 6.000-60.00-600.0-1000V
• DC voltage range: 600.0m-6.000-60.00-600.0-1000V
• AC current range: 60.00-600.0A
• DC current range: 60.00-600.0A
• Resistance range: 600.0-6.000k-60.00k-600.0k-6.000M-60.00M
• Capacitance range: 40.00n-400.0n-6.000u-60.00u-400.0u-4000uF
• Frequency range: 99.99-999.9-9.999k-60.00kHz
• Temperature range: -20-760°C
• Audible continuity function
• Diode test voltage: 2.8V
