UNIMIG 390A WORKSHOP 390 SWF MIG Electric Welder KUM390SWF

Features

• Powerful WORKSHOP 390 SWF MIG Welder with smooth arc performance
• Ideal for medium to heavy fabrication and rural tasks
• 30 position voltage switching for precise welding adjustments
• Four geared roller drive for consistent wire feeding
• High-quality copper-wound transformer with enhanced cooling
• KT50 Separate Wire Feeder extends reach by 10 metres
• Enclosed wire feeder design prevents dust and moisture contamination
• Constructed with durable components for reliability
• Suitable for mild steel, aluminium, and stainless steel
• MIG welding current range of 30-375A
• MIG wire size range of 0.6-2.4mm

Specifications

• Primary Input Voltage: 415V Three Phase
• Supply Plug: Three Phase (32 AMP Recommended)
• Rated Input Power (kVA): 16.0
• Rated Output: 30-375A
• Protection Class: IP21
• Insulation Class: I
• Minimum Generator (kVA): 19.0
• Dinse Connector: 35/50
• Standard: AS/NZ60974-1
• MIG Duty Cycle @ 40°C: 40% @ 355A
• MIG Wire Spool Size: 5kg/15kg
• MIG Welding Thickness Range: 2-20mm
• Drive Roller Size: 40/32 (x2)
• Warranty: 3 Year
• Net Weight: 136 kg
• Dimensions: 980mm (L) x 660mm (W) x 460mm (H)
