TOHO 2ton 3m 240V Single Phase Electric Chain Hoist TECH0203

TOHO 2ton 3m 240V Single Phase Electric Chain Hoist TECH0203

$4,158.00 AUD
$5,544.00 AUD $4,158.00 AUD
Sale Sold out
Taxes included. Shipping calculated at checkout.

Limited offer: $10 OFF orders above $250 using code 10OFF

Features

  • Japanese technology
  • High-efficiency motor in a lightweight, compact design
  • Pressed steel structure for high-strength body
  • Grade 80 - 7.1mm alloy steel load chain
  • Thermal overload prevention
  • Limit switches to prevent chain runout at top and bottom
  • High tensile alloy steel top and bottom hooks
  • 240V, 50Hz single speed motor, 1200 watts
  • Complies with ASNZS1418.2 standard
  • Re-chaining to required length allowed (limits apply)

Specifications

  • Capacity: 2 ton
  • Standard Lift: 3 m
  • Running Test Load: 25 kN
  • Motor Power: 1.2 kW
  • No. of Chains: 1
  • Diameter of Chain: 7.1 mm
  • Lifting Speed: 3 m/min
  • Extra Weight per meter of lift: 2.2 kg
  • Part No: TECH0203
  • Barcode: 9343662004704
  • Brand: TOHO
  • Warranty: 1 Year
  • Net Weight: 65 kg
  • Product Length: 560 mm
  • Product Width: 480 mm
  • Product Height: 380 mm
``
