FLUKE 1664 FC Installation Multifunction Testers FLU1664FC FVF FLU1664FC FVF

Features

• Fluke 1664 FC Multifunction Installation Tester for quick installations
• Real-time test result sharing via smartphone
• "Insulation PreTest" feature prevents damage by warning of connected appliances
• Auto Test performs multiple tests in one sequence for compliance
• Fluke Connect-enabled for cloud storage and team collaboration
• Compact and lightweight (under 1.3 kg) with padded neck strap
• Simple rotary dial for easy function selection
• High current loop mode for faster measurements
• Z-max memory for loop test evaluations
• Unique zero adapter for test lead compensation
• Fast voltage measurement using mains cord without changing connections
• Simultaneous measurement of RCD trip current and time
• Displays PEFC or PSC alongside loop impedance on dual display
• Ring testing with soft keys for easy input selection
• Continuity test currents for motor windings measurement
• Detects dangerous raised earth voltages using Earth Volt Touchpad
• Large backlit display with wide viewing angle for clear readings
• Extended three-layer memory for data management

Specifications

• AC voltage measurement: 500 V range, 0.1 V resolution, 0.8% + 3 accuracy
• Input impedance: 360 k
• Overload protection: 660 V rms
• Continuity testing (RLO): 20 / 200 / 2000 range, 0.01 / 0.1 / 1 resolution
• Insulation resistance measurement: Test voltages of 50-100-250-500-1000 V
• Insulation resistance range: 20 M to 1000 M
• Loop and line impedance range: 10 / 0.001 / High current m mode
• Prospective earth fault current range: 1000 A / 10 kA (50 kA)
• RCD testing types: AC, G, S
• Tripping speed test: 10-1000 mA current settings
• Earth Resistance Test range: 200 / 2000
• General size: 10 x 25 x 12.5 cm
• Weight: 1.3 kg (incl. batteries)
• Battery size: Type AA, 6 pcs
• Sealing: IP-40
• Safety compliance: EN61010-1, UL61010, ANSI/ISA s82.02.01, CAN/CSA c22.2 No. 1010
• Overvoltage category: CAT III / 500V; CAT IV 300V
