FLUKE 1000V Remote Display True RMS AC DC Clamp Meter w. Iflex FLU381

Features

• Single technician can perform tasks previously needing two people
• Clamp Fluke 381 around conductor and operate controls remotely
• Real-time readings visible while working from a distance
• iFlex Flexible Current Probe extends measurement range to 2500 A AC
• 6-foot cord for measuring tight spaces and awkward conductors
• Wireless technology allows display to be 30 ft away without accuracy loss
• Removable magnetic display can be mounted for visibility
• Integrated low pass filter for stable readings in noisy environments
• Proprietary inrush measurement technology captures motor starting current accurately
• Ergonomic design allows use while wearing protective gear
• Radio transmitter sets correct measurement range automatically
• Includes soft carrying case
• Safety Conformance: IEC/EN 61010-1:2001, 1000V CAT III, 600V CAT IV

Specifications

• AC Current via Jaw: Range: 999.9 A | Resolution: 0.1 A | Accuracy: 2% ± 5 digits (10-100 Hz), 5% ± 5 digits (100-500 Hz)
• AC Current via Flexible Current Probe: Range: 999.9 A / 2500 A (45 Hz 500 Hz) | Resolution: 0.1 A / 1 A | Accuracy: 3% ± 5 digits
• DC Current: Range: 999.9 A | Resolution: 0.1 A | Accuracy: 2% ± 5 digits
• AC Voltage: Range: 600 V /1000 V | Resolution: 0.1 V / 1 V | Accuracy: 1.5% ± 5 digits (20 500 Hz)
• DC Voltage: Range: 600.0 V /1000 V | Resolution: 0.1 V / 1 V | Accuracy: 1% ± 5 digits
• Frequency Via Jaw: Range: 5.0 500.0 Hz | Resolution: 0.1 Hz | Accuracy: 0.5% ± 5 digits
• Frequency via Flexible Current Probe: Range: 5.0 to 500.0 Hz | Resolution: 0.1 Hz | Accuracy: 0.5% ± 5 digits
• Resistance: Range: 600 /6 k /60 k | Resolution: 0.1 /1 /10 | Accuracy: 1% ± 5 digits
• Jaw Opening: 34 mm
• Flexible Current Probe Diameter: 7.5 mm
• Flexible Current Probe Cable Length: 1.8 m
• Operating Temperature: -10°C to +50°C
• Storage Temperature: -40°C to +60°C
• Operating Humidity: Non-condensing
• Operating Altitude: 2,000 meters
• Storage Altitude: 12,000 meters
• Wireless Frequency: 2.4 GHz ISM Band 10 meter range
• Double Insulation Clearance: Per IEC 61010-2-032
• Double Insulation Creepage: Per IEC 61010-1
